Mesh Extract By UV Shell

Mesh/Modifier

Extracts a mesh that represents the selected UV shells.
This works by sampling a position on the mesh and evaluating it's adjacent polygons in the UV space.

By sampling a 3D position to evalute the UV space, the extracted mesh is robust to changes to the mesh's UV topology.

Input Parameters

  • Mesh Mesh
  • Tolerance Float
  • NormalizedPosition Boolean
  • BVH Resource

Positions

  • UsePositionArray Boolean
  • PositionArray Resource
  • Count Uint
  • Position1 Vec3
  • Position2 Vec3
  • Position3 Vec3
  • Position4 Vec3
  • Position5 Vec3
  • Position6 Vec3
  • Position7 Vec3
  • Position8 Vec3
  • Position9 Vec3
  • Position10 Vec3
  • Position11 Vec3
  • Position12 Vec3
  • Position13 Vec3
  • Position14 Vec3
  • Position15 Vec3
  • Position16 Vec3
  • Position17 Vec3
  • Position18 Vec3
  • Position19 Vec3
  • Position20 Vec3
  • Position21 Vec3
  • Position22 Vec3
  • Position23 Vec3
  • Position24 Vec3
  • Position25 Vec3
  • Position26 Vec3
  • Position27 Vec3
  • Position28 Vec3
  • Position29 Vec3
  • Position30 Vec3
  • Position31 Vec3
  • Position32 Vec3
  • Position33 Vec3
  • Position34 Vec3
  • Position35 Vec3
  • Position36 Vec3
  • Position37 Vec3
  • Position38 Vec3
  • Position39 Vec3
  • Position40 Vec3

Output Parameters

  • Output Mesh

Meta

AuthorInstaMaterial GmbH
CategoryMesh/Modifier
TooltipExtracts a mesh that represents the selected UV shells. This works by sampling a position on the mesh and evaluating it's adjacent polygons in the UV space. By sampling a 3D position to evalute the UV space, the extracted mesh is robust to changes to the mesh's UV topology.
NameMesh Extract By UV Shell
Version1.45
IDbd611b92-47f9-4a89-b7a6-bbd6eb01fa65
PackageUrlpkg://8109350f-efd9-4e72-9887-0e268dc2787e/atoms/bd611b92-47f9-4a89-b7a6-bbd6eb01fa65.atom
