Mesh Boolean

Constructive solid geometry is a solid modeling technique that enables the creation of highly complex surfaces or objects by using boolean operators to combine objects. By using CSG it's easy to generate visually complex objects by combining basic primitives. InstaMAT's CSG is a powertool that does not require solids to work, but instead works using polygon meshes.

It's best to use CSG operation before generating UVs or other mesh attributes such as vertex normals as the CSG operation currently discards all mesh attributes.> The CSG node requires the input meshes to be watertight polygon mesh. If the mesh is not watertight, InstaMAT's CSG algorithm will still work but may produce unexpected results.

Input Parameters

• MeshA Mesh
  The input mesh A.
• MeshB Mesh
  The input mesh B.
• Mode Enum · Union, Intersection, Difference, Symmetric Difference
  The CSG operation to execute.
• NormalAngleThreshold Float
  Normals with a value lower than the specified value will be smoothed.
• InvertOrder Boolean
  Inverts the order of the operation, e.g. instead of subtracting B from A, A will be subtracted from B.
• Preview Boolean
  If enables the node will only append MeshB to MeshA to quickly preview the transformation. This is helpful when dealing with complex meshes as the CSG execution can become quite time intensive.

MeshA

• TranslateMeshA Vec3
  The translation.
• RotateMeshA Vec3
  The rotation in euler angles.
• ScaleMeshA Vec3
  The scale.
• PivotMeshA Enum · MeshCenter, MeshOrigin, Custom
  The pivot use for rotation and scale.
• CustomPivotMeshA Vec3
  The custom pivot, specified using normalized coordinates.
• NormalizedPositionMeshA Boolean
  If enabled, the translation is normalized by the mesh bounding box.
• AbsolutePositionMeshA Boolean
  If enabled, the translation is absolute, the mesh pivot will be moved to the specified translation coordinate.

MeshB

• TranslateMeshB Vec3
  The translation.
• RotateMeshB Vec3
  The rotation in euler angles.
• ScaleMeshB Vec3
  The scale.
• PivotMeshB Enum · MeshCenter, MeshOrigin, Custom
  The pivot use for rotation and scale.
• CustomPivotMeshB Vec3
  The custom pivot, specified using normalized coordinates.
• NormalizedPositionMeshB Boolean
  If enabled, the translation is normalized by the mesh bounding box.
• AbsolutePositionMeshB Boolean
  If enabled, the translation is absolute, the mesh pivot will be moved to the specified translation coordinate.

Output Parameters

• Output Mesh

Meta

Author	InstaMaterial GmbH
Category	Mesh/Modifier
Tooltip	Constructive solid geometry is a solid modeling technique that enables the creation of highly complex surfaces or objects by using boolean operators to combine objects. By using CSG it's easy to generate visually complex objects by combining basic primitives. InstaMAT's CSG is a powertool that does not require solids to work, but instead works using polygon meshes. > It's best to use CSG operation before generating UVs or other mesh attributes such as vertex normals as the CSG operation currently discards all mesh attributes.> The CSG node requires the input meshes to be watertight polygon mesh. If the mesh is not watertight, InstaMAT's CSG algorithm will still work but may produce unexpected results.
Name	Mesh Boolean
Version	1.0
ID	deadc0de-0c01-0000-0000-000000000013
