Quad Transform
Image/Transform
Performs a 2D rectangle transform (with configurable points) on the input image.
Input Parameters
- Input Image
- Normal Image
- Background Image
- Mode Enum · Default, Safe Transform, Non-Square Transform, Quad Transform, WrapTransform
- Symmetry Enum · None, Horizontal, Vertical, Horizontal & Vertical
Flips the image in the specified direction. - BlendMode Enum · Default, Additive, Signed Add, Minimum, Maximum, MaximumAlpha
- InputType Enum · Image, NormalMap
Applies a transformation correction when the supplied image is a normal map. - TilingMode Enum · Automatic, Manual
The tiling mode to be used in non-square transform mode. - TileCount UVec2
- AlphaThreshold Float · Range 0.00 → 1.00
Normal Map
- NormalFormat Enum · OpenGL, Blender, Maya, RSX, Unity, DirectX, 3DS Max, Unreal
- ScaleAndSkew Boolean
Handles scale & skew transformations when utilizing the Transform Normals correction.
Quad Transform
- TopLeft Vec2
- TopRight Vec2
- BottomLeft Vec2
- BottomRight Vec2
- CullingMode Enum · Front only, Back only, Front first, Back first
The culling mode when in Quad Transform mode.
Sampling
- Filtering Enum · Bilinear Smooth, Bilinear, Nearest
- MipRange UVec2
- MSAA Enum · Disabled, 2 Samples, 4 Samples, 8 Samples
- SamplingHorizontal Enum · Repeat, Clamped, Clamped Border
- SamplingVertical Enum · Repeat, Clamped, Clamped Border
- BorderColor Vec4
Transform
- TransformMode Enum · ScaleTranslateRotate, TranslateScaleRotate
- Rotate Float
- RotateSnap Float
Rotate angle increment snap for safe tile mode. - RotateScaleSnap Uint · Range 1 → 16
Maximum allowed scale correction for the rotation angle snap. - Scale Vec2
- Translate Vec2
- Pivot Vec2
Output Parameters
- Output Image
Material
- Normal Image
Example
Meta
| Author | InstaMaterial GmbH | Category | Image/Transform | Tooltip | Performs a 2D rectangle transform (with configurable points) on the input image. | Name | Quad Transform | Version | 1.1 | ID | 78809ad2-52b3-440b-9aab-661df04c27b8 | PackageUrl | pkg://b2f0620c-0b0e-4fbc-b6b6-e19ae59ce075/atoms/78809ad2-52b3-440b-9aab-661df04c27b8.template |
|---|
