Tile
Image/Tiling
Tiles the input image.
Input Parameters
- Image1 Image
- Image2 Image
- Image3 Image
- Image4 Image
- Image5 Image
- Image6 Image
- Image7 Image
- Image8 Image
- Image9 Image
- Background Image
- Count UVec2
- PreserveScaleRatio Boolean
- FloodFill Boolean
Advanced
- Filtering Enum · Bilinear Smooth, Bilinear, Nearest
- MipRange UVec2
- MSAA Enum · Disabled, 2 Samples, 4 Samples, 8 Samples
Color
- BlendMode Enum · Default, Add, SignedAdd, Minimum, Maximum
- AlphaThreshold Float · Range 0.00 → 1.00
Luminance
- ModeLuminance Enum · Default, Column, Row, Row + Column, Size, Random Add Sub
- FactorLuminance Float · Range 0.00 → 1.00
- VarianceLuminance Float · Range 0.00 → 1.00
Mask
- MaskMode Enum · Density, Image Input, Column, Row, Row + Column, Checkerboard, Period
- MaskPeriod UVec2
- InputMask Image Gray
- InputThresholdMask Float · Range 0.00 → 1.00
- DensityMask Float · Range 0.00 → 1.00
- InvertMask Boolean
Offset
- DistanceOffset Float · Range 0.00 → 1.00
- RepeatPeriodOffset Uint
- VarianceOffset Float · Range 0.00 → 1.00
- VerticalOffset Boolean
Pattern
- PatternCount Uint · Range 1 → 9
- DistributionMode Enum · Random, Priority Random, Tile Number
- PatternVariance Float · Range 0.00 → 1.00
- RotationModePattern Enum · Default, Checkerboard, Truchet, 45 Angle, 45 Angle + Truchet
- FlipModePattern Enum · None, Horizontal, Vertical, Horizontal + Vertical
- RotationVariancePattern Float · Range 0.00 → 1.00
- FlipVariancePattern Float · Range 0.00 → 1.00
Size
- Size Float · Range 0.00 → 1.00
- SizeVariance Float · Range 0.00 → 1.00
- MiddleSplit Vec2
- GapSize Vec2
- GapVariance Vec2
Output Parameters
- Output Image
- Floodfill Image
Meta
| Author | InstaMaterial GmbH | Category | Image/Tiling | Tooltip | Tiles the input image. | Name | Tile | Version | 1.122 | ID | c58c9e50-9897-402b-97a7-e325802f6d8e | PackageUrl | pkg://fae52066-2555-4f99-8332-b4b6d05e1a30/atoms/c58c9e50-9897-402b-97a7-e325802f6d8e.atom |
|---|
