Mesh Scatter On PointCloud

Scatters the input meshes on the pointcloud.

Input Parameters

• Count Uint
  Determines how many iterations the graph will execute.
• ScatterMeshCount Uint · Range 1 → 8
• PointCloud Point Cloud
• ScatterMesh1 Mesh
• ScatterMesh2 Mesh
• ScatterMesh3 Mesh
• ScatterMesh4 Mesh
• ScatterMesh5 Mesh
• ScatterMesh6 Mesh
• ScatterMesh7 Mesh
• ScatterMesh8 Mesh
• ScatterMeshUpAxis Enum · X, Y, Z
• ScatterMeshPivot Enum · MeshCenter, MeshOrigin, Custom
• CustomScatterMeshPivot Vec3
• OrientToNormal Boolean
• Cancellation Boolean
  Prevents the intersection of scattered meshes.
• CancellationRadius Float
  Determines the influence radius of the scatter cancellation. If a new scatter would fall within the cancellation radius of a previous scatter, it will not be discarded. The radius is measured in relation to the bounding sphere of the mesh.

RandomTransform

• MinimumTranslate Vec3
• MaximumTranslate Vec3
• MinimumRotate Vec3
• MaximumRotate Vec3
• MinimumScale Vec3
• MaximumScale Vec3
• ProportionalScale Boolean

Output Parameters

• Output Mesh
