Compute Histogram
Image/Advanced
Computes the histogram data for the input image. Optionally, the node can visualize the histogram data that was generated by the node.
Input Parameters
- Input Image
- Mode Enum · Default, CumulativeDistribution, Normalized
- Draw Boolean
- VisualizeAlpha Boolean
- Softness Float · Range 0.00 → 1.00
- Factor Float · Range 1.00 → 10.00
- Threshold Float · Range 0.00 → 1.00
- HighPrecision Boolean
If enabled, uses the higher 16-bit range for the histogram bins, otherwise 8-bit.
Output Parameters
- Output Image
- MinimumValues UVec4
- NonZeroMinimumValues UVec4
- MaximumValues UVec4
- MinimumValue Uint
- NonZeroMinimumValue Uint
- MaximumValue Uint
- MinimumCumulativeValues Vec4
- MinimumCumulativeValue Float
- Histogram Image
Example
Meta
| Author | InstaMaterial GmbH | Category | Image/Advanced | Tooltip | Computes the histogram data for the input image. Optionally, the node can visualize the histogram data that was generated by the node. | Name | Compute Histogram | Version | 1.48 | ID | 2d0ffb92-fcaf-4d3e-8eef-84256f2f535d | PackageUrl | pkg://09964c6a-8eb4-4710-8499-f660b48d35b7/atoms/2d0ffb92-fcaf-4d3e-8eef-84256f2f535d.atom |
|---|
