Mesh Plane Mirror

Mirrors the input mesh by over a plane that can be freely translated and rotated. Parts of the mesh that are behind the plane will be clipped.

Input Parameters

• Mesh Mesh
• Translate Vec3
  The plane translation.
• Rotate Vec3
  The plane rotation in euler angles.
• NormalizedPosition Boolean
  If enabled, the translation is normalized by the mesh bounding box.
• MergeAndWeld Boolean
  If enabled, the mirrored meshes will be merged into the input submeshes, otherwise new submeshes will be created. Additionally, unless a split is required due to vertex attributes such as normals or UVs, the vertices will be welded.

Output Parameters

• Output Mesh
