Mesh UV Pack

Input Parameters

• Mesh Mesh
• ShellRotation Enum · None, Allow90, Arbitrary
  Enable to allow shells to be rotated for improved packing. Disabling rotations can cause certain scenarios to be unpackable.
• TargetTextureSize UVec2
  The size in pixels of the target texture.
• GutterSizeInPixels Uint
  The minimum distance between two UV shells in pixels.
• InsertNormalSplits Boolean
  Insert UV shell splits for edges that do not share the same wedge normals.
• StackDuplicateShells Boolean
  Places duplicate UV shells referencing the same material ID on top of each other to save UV space.

Output Parameters

• Output Mesh

Meta
