Mesh Image Atlas
Mesh/Utility
Generate a grid atlas from one or multiple mesh inputs, with configurable transformations.
Input Parameters
- Count Uint
- InputCount Uint
- Mesh1 Mesh
- Mesh2 Mesh
- Mesh3 Mesh
- Mesh4 Mesh
- Mesh5 Mesh
- Mesh6 Mesh
- Mesh7 Mesh
- Mesh8 Mesh
- Mesh9 Mesh
- Mesh10 Mesh
- Mesh11 Mesh
- Mesh12 Mesh
- Mesh13 Mesh
- Mesh14 Mesh
- Mesh15 Mesh
- Mesh16 Mesh
- InputMode Enum
- InputVariance Float
- Orientation Vec3
- OrientationVariance Vec3
- Scale Vec3
- ScaleVariance Vec3
- ScaleVarianceMode Enum
- ScaleMaximum Vec3
- AutoScale Boolean
- FloodFill Boolean
- NormalOutput Boolean
- NormalFormat Enum
- SizeOutput Boolean
- Antialiasing Boolean
Output Parameters
- Floodfill Image
- Size Image Gray
Material
- Height Image Gray
- Normal Image
Meta
| Author | InstaMaterial GmbH | Category | Mesh/Utility | Tooltip | Generate a grid atlas from one or multiple mesh inputs, with configurable transformations. | Name | Mesh Image Atlas | Version | 1.49 | ID | 555f04d1-1afa-4f26-8350-f06650b44f20 | PackageUrl | pkg://7acc9011-6d5d-4855-aff4-f2df8fbd9a20/atoms/555f04d1-1afa-4f26-8350-f06650b44f20.atom |
|---|
