Synthesis Advanced
Image/Synthesis
Advanced synthesis node that can generate tileable texture from one or multiple inputs and is best suited for stochastic inputs (i.e. more random).
Input Parameters
- InputCount Uint · Range 1 → 4
- Input1 Image
- Input2 Image
- Input3 Image
- Input4 Image
- Scale Uint · Range 1 → 5
- Quality Enum · Low, Medium, High, Ultra
- FilteringMode Enum · Nearest, Bilinear, Bicubic
- Preview Boolean
Advanced
- ComputeSourceMap Boolean
- PyramidLevels Uint · Range 2 → 6
- PyramidFilteringMode Enum · Nearest, Bilinear, Bicubic
- FadeFactor Float · Range 0.00 → 1.00
Values closer to zero will produce steep borders while closer to one will produce smoother ones. - Seamless Boolean
- RandomSeeds Boolean
- Deterministic Boolean
Output Parameters
- Output Image
- SourceMap Image
Meta
| Author | InstaMaterial GmbH | Category | Image/Synthesis | Tooltip | Advanced synthesis node that can generate tileable texture from one or multiple inputs and is best suited for stochastic inputs (i.e. more random). | Name | Synthesis Advanced | Version | 1.224 | ID | c2759b1e-4124-49cf-b741-c200fdce3291 | PackageUrl | pkg://d7517a92-b83f-468c-9549-1df63a2ce860/atoms/c2759b1e-4124-49cf-b741-c200fdce3291.atom |
|---|
