Mesh UV Unwrap

Input Parameters

• Mesh Mesh
• Strategy Enum · Organic, HardSurfaceAngle, HardSurfaceAxial, Auto
  The unwrap strategy used by the unwrap operation.
• StretchImportance Enum · Off, Lowest, Low, Normal, High, Highest
  The importance of UV space stretch during the unwrap. Off: high levels of stretch allowed, Highest: no stretching allowed. Stretch impacts the UV-shell and vertex split count. Allowing for higher stretch values means less UV-shells generated.
• TargetTextureSize UVec2
  The size in pixels of the target texture.
• GutterSizeInPixels Uint
  The minimum distance between two UV shells in pixels.
• InsertNormalSplits Boolean
  Insert UV shell splits for edges that do not share the same wedge normals.

Output Parameters

• Output Mesh
